3.4.2.8 Creating profiles
Profiles for setting camera parameters in uc480 Viewer
Profile files for uc480 Viewer are text files with the file name extension *.ucp. As opposed to uc480 parameter files
(ini files), profiles are not tied to a specific camera model and do not contain all the camera settings. Some
parameters in profiles are relative settings (e.g. exposure 0-100 %) to ensure compatibility with all camera models.
You can create new profiles and load them from the start dialog . When you start uc480 Viewer, the application
searches the C:\Program Files\IDS\uc480\Program\ folder for profile files and lists them in the Profiles
menu . The profile names shown in the menu are named after the files.
Attention
Do not remove or rename the profile files created in the C:\Program Files\Thorlabs\DCx Cameras
\Profile\ folder when you install the application. Otherwise program functions in uc480 Viewer may not work
correctly.
Note
The profiles are a feature of uc480 Viewer. They cannot be used through the uc480 API.
Structure of a profile file for setting camera parameters
Profile files have the structure described below. They do not have to contain all the parameters listed here.
Parameter
Description
[DISPLAY]
PIXEL_FORMAT
Color format
see also is_SetColorMode()
RENDER_MODE
Render mode (DIB, Direct3D, OpenGL)
see also Image display modes and is_SetDisplayMode()
FIT_TO_WINDOW
Fits the image to the window
[TIMING]
PIXELCLOCK
Pixel clock in MHz
see also Pixel clock, frame rate, exposure time and is_PixelClock()
FRAMERATE
Frame rate 0-100 %
see also is_SetFrameRate()
EXPOSURE
Exposure time 0-100 %
see also Is_Exposure()
[COLOR]
CORRECTION_FACTOR
Color correction factor 0-100 %
see also is_SetColorCorrection()
SATURATION_U
Color saturation 0-2x
see also is_SetSaturation()
SATURATION_V
Color saturation 0-2x
see also is_SetSaturation()
[IMAGE_PARAMETERS]
EDGE_ENHANCEMENT
Edge enhancement
see also is_EdgeEnhancement()
GAMMA
Gamma correction
see also is_SetGamma()
[AES_AGC_AFR]
EXPOSURE
Auto exposure shutter
see also is_SetAutoParameter()
GAIN
Auto gain control
see also is_SetAutoParameter()
FRAMERATE
Auto frame rate setting for auto exposure shutter
see also is_SetAutoParameter()
