© 2013 Thorlabs GmbH466
DCx Cameras
5.3.3 DCC1645C
Sensor specification
Sensor type
CMOS
Shutter system
Electronic rolling shutter
Characteristic
Linear
Readout mode
Progressive scan
Resolution class
SXGA
Resolution
1280 x 1024 pixels (1.31 Megapixel)
Aspect ratio
5:4
Bit depth
10 bits
Optical sensor class
1/3 inch
Exact sensitive area
4.608 x 3.686 mm
Exact optical sensor diagonal
5.90 mm (1/2.71 inch)
Pixel size
3.60 µm, square
Micro lens shift
25°
Sensor name
Aptina MT9M131 (color)
Gain
Color model (master/RGB)
4.27x / 3.1x
Analog gain boost
2.0x
Camera timing
Pixel clock range
MHz
5 to 40
*1
Max. pixel clock with subsampling/binning
MHz
40
*1
Frame rate (freerun mode)
fps
25.0
*2
Frame rate (trigger mode, 1 ms exposure)
fps
24.9
*2
Exposure time in freerun mode
ms
0.037
*2
to 10122
*3
Exposure time in trigger mode
ms
0.037
*2
to 10122
*3
AOI
Mode
Horizontal
*4
+ Vertical
*4
AOI image width, step width
Pixels
32 to 1280, 4
AOI image height, step width
Pixels
4 to 1024, 2
AOI position grid horizontal, vertical
Pixels
4, 2
AOI frame rate, 1280 x 720 pixels (HD
720)
fps
34
AOI frame rate, 800 x 600 pixels (SVGA)
fps
61
Binning
Mode
none
Subsampling
Mode
Horizontal
*4
+ Vertical
*4
Method
H + V: Color subsampling
Factor
2x, 4x
Frame rate w/ 2x subsampling, 640 x 480
pixels
fps
89
Frame rate w/ 4x subsampling, 320 x 240
pixels
fps
263
Hardware trigger
Mode
Asynchronous
41
25
