Page #14 background imageLoading...
Page #14 background image
© 2013 Thorlabs GmbH12
DCx Cameras
1.2 Ordering Codes and Accessories
DCU223M
CCD camera, monochrome, 1024x768 pixel, C mount
DCU223C
CCD camera, color, 1280x1024 pixel, C mount
DCU224M
CCD camera, monochrome, 1280x1024 pixel, C mount
DCU224C
CCD camera, color, 1280x1024 pixel, C mount
DCC1545M
CMOS camera, monochrome, 1280x1024 pixel, CS mount
DCC1645C
CMOS camera, color, 1280x1024 pixel, CS mount
DCC1240M
CMOS camera, monochrome, 1280x1024 pixel, C mount
DCC1240C
CMOS camera, color, 1280x1024 pixel, C mount
CAB-DCU-T1
Trigger cable for DCU22xX and DCC1240X cameras (Trigger In/Out)
CAB-DCU-T2
Trigger cable for DCU22xX and DCC1240X cameras (Trigger In only)
CAB-DCU-T3
I/O cable for DC3240 CMOS USB 3.0 cameras
Thorlabs C Mount Camera Lenses (objectives): See Thorlabs' website
1.3 Requirements
For operating the DCx cameras, the following system requirements must be met:
Minimum
*1
Recommended
CPU speed
600 MHz
2 x 2.4 GHz
Memory (RAM)
256 MB
2048 MByte
USB host controller
USB 2.0 high speed (480 Mbps)
USB 3.0 (4000 Mbps) for DC3240x
cameras
USB 2.0 high speed (480 Mbps)
USB 3.0 (4000 Mbps) for DC3240x cameras
Intel
®
or NVIDIA
®
nForce mainboard chipset
Graphics card
Onboard graphics chip
AGP/PCIe graphics card
Latest version of Microsoft DirectX Runtime
9.0c
Operating system
Windows 7 32 or 64 bit
Windows XP 32 bit (Service Pack 2)
Linux (Kernel 2.6)
Windows 7 32 or 64 bit
Windows Vista 32 or 64 bit (Service Pack 1)
*3
Windows XP 32 bit (Service Pack 3)
Linux (Kernel 2.6)
*
1
With the minimum system requirements the camera performance may be limited.
*
3
DCC3240x USB 3.0 cameras are not supported under Windows Vista.
USB interface
Onboard USB 2.0 ports usually provide significantly better performance than PCI and PCMCIA USB adapters.
Current generation CPUs with energy saving technologies can cause bandwidth problems on the USB bus. See
section PCs with energy saving CPU technology for hints and possible solutions.
Large multi camera systems
Connecting a large number of cameras to a single PC may require a large working memory (RAM). This is
especially the case when many cameras with high sensor resolution are used.
If you want to set up such a system we recommend to use PCs with 64 bit operating systems and more than 4 GB
of RAM.
Note
For DCx color cameras, the color conversion is done by software in the PC. When you use a color camera with a
high frame rate, the conversion might lead to a high CPU load. Depending on the PC hardware used you might not
be able to reach the camera's maximum frame rate.
Direct3D graphics functions
The uc480 driver can use Direct3D to display the camera image with overlay information (Microsoft DirectX
500
