© 2013 Thorlabs GmbH262
DCx Cameras
the current camera model.
IS_INVALID_CAMERA_HANDLE
Invalid camera handle
IS_INVALID_PARAMETER
One of the submitted parameters is outside the valid
range or is not supported for this sensor or is not
available in this mode.
IS_IO_REQUEST_FAILED
An IO request from the uc480 driver failed. Possibly the
versions of the uc480_api.dll (API) and the driver file
(uc480_usb.sys) do not match.
IS_NO_SUCCESS
General error message
IS_NOT_CALIBRATED
The camera does not contain any calibration data.
IS_NOT_SUPPORTED
The camera model used here does not support this
function or setting.
IS_NULL_POINTER
Invalid array
IS_OUT_OF_MEMORY
No memory could be allocated.
IS_SUCCESS
Function executed successfully
IS_TIMED_OUT
A timeout occurred. An image capturing process could
not be terminated within the allowable period.
Example 1
// Enable/disable correction
INT nRet = is_HotPixel(hCam, IS_HOTPIXEL_DISABLE_CORRECTION, NULL, NULL);
nRet = is_HotPixel(hCam, IS_HOTPIXEL_ENABLE_CAMERA_CORRECTION, NULL, NULL);
nRet = is_HotPixel(hCam, IS_HOTPIXEL_ENABLE_SOFTWARE_USER_CORRECTION, NULL, NULL);
nRet = is_HotPixel(hCam, IS_HOTPIXEL_ENABLE_SENSOR_CORRECTION, NULL, NULL);
nRet = is_HotPixel(hCam, IS_HOTPIXEL_DISABLE_SENSOR_CORRECTION, NULL, NULL);
Example 2
// Read out current mode
INT nMode = 0;
INT nRet = is_HotPixel(hCam, IS_HOTPIXEL_GET_CORRECTION_MODE,
(void*)&nMode, sizeof(nMode));
// Query supported modes
INT nRet = is_HotPixel(hCam, IS_HOTPIXEL_GET_SUPPORTED_CORRECTION_MODES,
(void*)&nMode, sizeof(nMode));
Example 3
// Query user-defined hot pixel list
INT nRet = is_HotPixel(hCam, IS_HOTPIXEL_GET_SOFTWARE_USER_LIST_EXISTS, NULL, NULL);
if (nRet == IS_SUCCESS)
{
// Query the number of hot pixels in the user-defined list
INT nNumber = 0;
nRet = is_HotPixel(hCam, IS_HOTPIXEL_GET_SOFTWARE_USER_LIST_NUMBER,
(void*)&nNumber, sizeof(nNumber));
if (nRet == IS_SUCCESS)
{
// Allocate sufficient memory. Each hot pixel needs two WORDS
// memory space.
// Additional memory space of one WORD per hot pixel is required for numbering.
WORD *pList = new WORD[1 + 2 * nNumber];
nRet = is_HotPixel(hCam, IS_HOTPIXEL_GET_SOFTWARE_USER_LIST,
(void*)pList, (1 + 2 * nNumber) * sizeof(WORD));
// Change a value and save the list.
// The number of the hot pixel has to be specified in pList[0]
pList[1] = 100;
nRet = is_HotPixel(hCam, IS_HOTPIXEL_SET_SOFTWARE_USER_LIST,
(void*)pList, (1 + 2 * nNumber) * sizeof(WORD));
// Delete unneeded list
delete [] pList;
}
}
