© 2013 Thorlabs GmbH432
DCx Cameras
hCam
Camera handle
camera model.
IS_GET_SUPPORTED_FLASH_IO_PORTS
Returns which of the general purpose I/Os (GPIO) can
be used for the flash strobe
Statically setting the output level
IS_SET_FLASH_HIGH
Statically sets the digital output to high level (HIGH).
IS_SET_FLASH_LOW
Statically sets the digital output to low level (LOW).
nLine
Currently not used
Return values
IS_SUCCESS
Function executed successfully
IS_NO_SUCCESS
General error message
When used with
IS_GET_FLASHSTROBE_MODE
Current setting
When used with
IS_GET_SUPPORTED_FLASH_IO_PORTS
Returns the supported ports linked by a logical OR.
IS_SET_FLASH_IO_1
IS_SET_FLASH_IO_2
Related functions
is_SetFlashDelay()
is_IO()
is_SetExternalTrigger()
is_SetTriggerDelay()
is_CaptureVideo()
Example
//Software trigger mode, HI_ACTIVE flash mode
is_SetExternalTrigger (hCam, IS_SET_TRIGGER_SOFTWARE);
is_SetFlashStrobe (hCam, IS_SET_FLASH_HI_ACTIVE, 0);
is_FreezeVideo (hCam, IS_WAIT);
// Flash additionally on second GPIO output
is_SetFlashStrobe (hCam, IS_SET_FLASH_HI_ACTIVE | IS_SET_FLASH_IO_2, 0);
// Flash only on normal flash output
is_SetFlashStrobe (hCam, IS_SET_FLASH_HI_ACTIVE, 0);
Sample programs
uc480 Flash Strobe (C++)
uc480 IO (C++)
429
280
327
352
177
