© 2013 Thorlabs GmbH
5 Specifications
479
Camera front (sectional view)
Note
Front Panel of the DCU223x / DCU224x housing
Models introduced before 2008 have a different front panel. On these models, the filter glass is held in the C-mount
lens connector by two screws. This front panel version is indicated by (V2) in the table below.
Camera
Type
Thread
depth
for diameter
at lens end
resulting max. immersion
depth (mm)
min. required back focal
length (mm)
(Ø A, B, C
in mm)
CMOS
CCD
CMOS
CCD
DCU223X
DCU224X
DCC1240X
C-mount
5 mm
24.0
6.9
6.4
6.4
6.9
20.0
9.4
8.9
14.1
11.1
10.6
DCU223X
(V2)
DCU224X
(V2)
C-mount
5 mm
24.0
-
8.4
-
7.8
17.1
-
9.2
14.1
-
9.7
DCC1545M
DCC1645C
CS-mount
4 mm
24.0
6.1
-
4.9
-
14.6
7.6
-
C-mount with
extension
ring
4 mm
*1
22.0
*1
11.1
-
14.6
*1
12.6
-
DCC3240x
C-mount
5 mm
24.0
7.2
-
6.8
-
20.4
9.7
-
14.6
10.7
-
*
1
May vary depending on the inside diameter of the extension ring used
*
2
Without IR cut filter
Note
The data given in the table include the following tolerances as a safety clearance:
Immersion depth: 0.2 mm
Diameter: 0.2 mm
