15-8
Twist Owner’s Manual
OM_TWIST_0811RevA
CHAPTER 15: TRANSPoRTATioN oPTioNS
been installed in accordance with the manufacturer’s instructions and SAE J2249. It is NOT compatible
with other types of WTORS.
Note: To obtain a copy of SAE J2249 Wheelchair Tie-Down and Occupant Restraint Systems
(WTORS) for use in Motor Vehicles, please contact SAE International, 400 Commonwealth Drive,
Warrendale, PA 15096-0001, USA. Telephone: 724-776-4970. Web: www.sae.org
3. This wheelchair MUST be positioned in a forward-facing position prior to engaging the WTORS.
4. The positions of the four wheelchair securement points (Tie-Down brackets) are shown in Figure 15-4.
Note: For Twist wheelchairs manufactured prior to October 2012, the two front securement points
were located as shown in Figure 15-5.
5. Each of the four Tie-Down brackets (see Figure 15-4) is identied with the symbol shown in Figure 15-6
Figure 15-4
Tie-Down Brackets
BACK VIEW
FRONT VIEW
Tie-Down
Brackets
Tie-Down
Brackets
