12-3
Twist Owner’s Manual
OM_TWIST_0811RevA
CHAPTER 12: REAR WHEELS
Tools required:
• 7/8” Open End Wrench
• 3/4” Open End Torque Wrench
1. Place the 7/8” Open End wrench onto the camber plug and use the 3/4” Open End Torque wrench to remove the
axle sleeve. See Figure 12-5.
Note: If you have only one washer and do not have a lock washer, your rear wheel spacing package will include a
lock washer. Always use a lock washer.
2. Add or delete the spacers you need to increase/ decrease your rear wheel spacing, keeping the two washers
against the head of the axle sleeve.
3. After you have adjusted your rear wheel spacing, reinstall the axle sleeve in the camber plug and hand-tighten.
4. Using a Torque wrench, tighten the axle sleeve to 230 inch-pounds.
Figure 12-5
Rear Wheel Spacing
1/8” Spacer
Camber Tube
Axle Sleeve
Camber Plug
Lock Washer
1/2” Spacer
1/4” Spacer
