TiLite Twist - Page 9

OM_TWIST_0811RevA
Twist Owner’s Manual
vii
Removing 5-2
Replacing 5-2
FLIP-BACK TUBULAR ARMREST 5-3
Adjusting the Armrest Height
5-3
Adjusting the Armrest Angle 5-4
CHAPTER 6: SIDE GUARDS 6-1
RIGID REMOVABLE & QUAD REMOVABLE SIDE GUARDS (Aluminum and Carbon Fiber) 6-1
Adjusting 6-1
Removing 6-2
Reinstalling
6-2
FENDERED CARBON FIBER SIDE GUARD
6-2
CHAPTER 7: BACK UPHOLSTERY, SEAT UPHOLSTERY & SEAT CUSHIONS 7-1
VELCRO
®
-STYLE ADJUSTABLE BACK UPHOLSTERY 7-1
Adjusting the Tension 7-1
Replacing 7-1
TENSION ADJUSTABLE BY STRAPS BACK UPHOLSTERY 7-2
Adjusting the Tension 7-2
Replacing 7-3
TENSION ADJUSTABLE BOLT-ON SEAT UPHOLSTERY 7-3
Adjusting the Tension 7-3
Replacing 7-4
SOLID ALUMINUM SEAT PAN 7-4
Removing/ Replacing 7-4
SEAT CUSHIONS 7-5
Replacing the Foam Insert in the TiLite Seat Cushion 7-5
VELCRO
®
-STYLE ADJUSTABLE SEAT BELT 7-5
Installation 7-5
Adjustment 7-6
Safety Check 7-6
Maintenance 7-6
CHAPTER 8: AXLE PLATES AND CAMBER PLUGS (CENTER OF GRAVITY;
REAR SEAT HEIGHT) 8-1
CAMBER MOUNTS 8-1
Adjusting the Rear Seat Height 8-1
Adjusting the Center of Gravity 8-2
Replacing the Camber Tube 8-3
ADJUSTING TOE-IN/TOE-OUT 8-3
CHAPTER 9: AXLES 9-1
STAINLESS AND TITANIUM QUICK RELEASE AXLES 9-1
Adjusting 9-1
QUAD RELEASE AXLES 9-2
Adjusting the Handle 9-2
Adjusting the “Play” 9-3
CHAPTER 10: WHEEL LOCKS 10-1
COMPACT COMPOSITE PUSH TO LOCK 10-1
Adjusting 10-1
Replacing 10-1
