TIM MIRUS Controller - Symbols on the Device

1 Introduction
10 IFU, MIRUS Controller, en-GB, N.00
11
Menu button Turn off (turn off device)
12
Button Stop: stops application of VA
13
Button MAC: displays unit and currently set value, setting MAC value.
14
Button Pause: pauses application of VA
15
Button Play: starts application of VA
16
Status symbol System test.
ST. System test was performed successfully.
No Test. System test is invalidated.
17
Status symbol battery: Power supply via battery (with capacity indicator) or
battery is in charging mode (symbol is animated).
18
Status symbol mains supply: device is powered by mains supply.
19
Status symbol application of VA.
MAC pilot: MAC pilot active - VA is applied
(animated synchronously to lifeline)
NO VA: VA application not active (stop or pause).
20
Status symbol Agent reservoir: liquid level (in anaesthetic agent colour).
21
Graphic Target reached level: current Fi/Fe ratio.
22
Status symbol Reflector: remaining allowed operation time (in anaesthetic agent
colour).
Note: For more information about further symbols used on screens please refer to this IFU
and to the Additional Information (AI) of MIRUS Controller chapter 1.3.
1.5 Symbols on the device
STK label (in Germany):
Indicates when the next safety check in accordance with §6
Medical Device Operator Ordinance (MPBetreibV) is required.
Warranty seal:
Warranty void if seal is broken.
Note: For more information about further symbols used on the equipment please refer to the
Additional Information (AI) of MIRUS Controller chapter 1.3.
