3 Preparation
IFU, MIRUS Controller, en-GB, N.00 31
3.11.1 Filling during operation
Filling-tab
Filling VA reservoir.
Note: Filling is also possible during
VA application.
Note: During application of VA, VA delivery is maintained during filling process, as long as
internal pressure is sufficient.
WARNING Always control the et VA concentration of the patient during filling as
it might decrease.
Note: Observe the warnings in chapter 3.5 Filling during start-up.
CAUTION Do not try to open the
flap manually, it could
be seriously damaged.
Press Fill port flap button.
Button Fill port flap is light grey.
Follow instruction on screen.
Fill port flap opens automatically.
