TIM MIRUS Controller - Patient Data Settings

10 Technical specifications
62 IFU, MIRUS Controller, en-GB, N.00
10.2.3 Patient data settings
Specification
Values
Age
Range: 10 to 115 years
Increment: 1 year @ single taps on button
5 years @ pressing button > 1 sec
Size
Range: 100 to 250 cm
Increment: 5 cm @ single taps on button
10 cm @ pressing button > 1 sec
Weight
Range: 15 to 125 kg (ideal body weight)
Increment: 1 kg @ single taps on button
5 kg @ pressing button > 1 sec
10.3 Performance
10.3.1 Agent dosage accuracy
For
Values
Isoflurane and
Sevoflurane and
Desflurane
+ 15% of set MAC (measured as average of MV)
@ all settings
- 15% of set MAC (measured as average of MV)
@ Vt = 500 mL, Rate = 15 /min, I:E = 1:2, MAC = 1.0
Wash-in speed = Turtle
Maximum rate = 40/min
10.3.2 Respiratory monitoring accuracy
Specification
Values
Volumes
± 15% @ Vt 200 mL to 2000 mL
(BTPS corrected, @rate < 40/min)
Pressures
± 4.0% or 2 cmH
2
O whichever is greater
@ -10 to 100 cmH
2
O (@rate < 40/min)
Rate
± 1 breath per minute (@rate < 40/min)
I:E
± 25% (@rate > 40/min)
