3 Preparation
IFU, MIRUS Controller, en-GB, N.00 37
Press Confirm button.
 Change completed.
3.13 Connecting patient
In order to connect the patient to the device you need a filter in addition to the reflector already
connected to the controller (refer to chapter 1.4.2 Exchanger unit).
Note: For information regarding the reflector and the filter and how to connect these
accessories with the patient and the controller please refer to the manufacturer’s
instructions for use (IFU).
When the patient is connected to the
controller, the lung icon is animated and the
controller measures an et CO
2
value.
