WDG 100H Errors and modifications reserved. © Wachendorff Automation GmbH & Co. KG 2022-04-19 -2-
Cable connection K3, L3 with 20 dm cable
DescriptionABN inv. poss.
L3radial, shield connected to encoder housing•
Assignments
Circuit
GND
(+) Vcc
A
B
N
Light reserve
warning
A inv.
B inv.
N inv.
Shield
L3
245
WH
BN
GN
YE
GY
-
RD
BK
VT
flex
