TKE TW45 - Machine base frame with rope pulley - left-hand version of the rope pulley position

Technology
Dimensions 45
TK Elevator
BA, TW45 | 6231003860 | 03/2023
Machine base frame with rope pulley - left-hand version of the
rope pulley position
Fig.21 ATR_2_21_0043_0
Project planning dimensions:
Traction sheave ver-
sion
Unit Rope pulley version (mm)
Diameter of traction
sheave Dt [mm]
D360 D450
ASL α ASL α ASL α ASL α
min max max min min max max min
440
(mm) /
(°)
592
167 832
149 576 168
776
150
520
(mm) /
(°)
672 154 616 170 157
Tab.18 ATR_1_21_0020_0
