Project planning dimensions:
Traction sheave ver-
sion
Unit Rope pulley version (mm)
Diameter of traction
sheave Dt [mm]
D360 D450
ASL α ASL α ASL α ASL α
min max max min min max max min
440
(mm) /
(°)
592
167 832
149 576 168
776
150
520
(mm) /
(°)
672 154 616 170 157
Tab.16 ATR_1_21_0020_0
Intermediate values for ASL in the modular dimension of 40 mm possible.
Distances:
Rope pulley version Unit Project planning dimension
(mm) x1 x2 y1 y2 z1
D360 (mm) 130 61 645 190 245
D450 (mm) 231 116 600 235 255
Tab.17 ATR_1_21_0021_0
