Toa A-9060DH - 26.6.3. C-001 T; 26.6.4. ZP-001 T

132
26.6.3. C-001T
26.6.4. ZP-001T
6 V DC
15 mA
8 channels, open voltage: 3.3 V DC, short-circuit: under 1 mA,
removable terminal block (9 pins)
8 channels, open collector output, withstand voltage: 27 V DC,
control current: max. 50 mA, removable terminal block (9 pins)
–10 to +40°C
Panel: Aluminum, hair-line
35 (w) x 78 (h) x 91.5 (d) mm
62 g
Power Source
Current Consumption
Control Input
Control Output
Operating Temperature
Finish
Dimensions
Weight
+24 V DC, +6 V DC
38 mA (at +24 V DC), 18 mA (at +6 V DC)
1 line
DTMF signal
Loop-Start (or Ground-Start, selectable)
0 dB, 600 Ω, balanced, transformer-isolated,
loop voltage: 24 V DC or more, RJ-11 connector
0 dB, 600 Ω, balanced, transformer-isolated audio input,
removable terminal block (4 pins)
1 channel, no-voltage make contact, open voltage: 5 V DC,
short-circuit: 0.5 mA, removable terminal block (4 pins)
4 channels, open collector output (isolated), withstand voltage: 35 V DC,
control current: max. 50 mA, removable terminal block (4 pins)
–10 to +40°C
Panel: Aluminum, hair-line
35 (w) x 78 (h) x 91.5 (d) mm
153 g
Power Source
Current Consumption
Number of Lines
Type of Selectable Signal
Signaling System
TEL Line
Paging Input
Control Input
Control Output
Operating Temperature
Finish
Dimensions
Weight
Note: The design and specifications are subject to change without notice for improvement.
• Accessories
Removable terminal plug (9 pins) .................... 2
Machine screw M3 x 8 ..................................... 2
Note: The design and specifications are subject to change without notice for improvement.
• Accessories
Removable terminal plug (4 pins) .................... 3
Machine screw M3 x 8 ..................................... 2
