1. Design the system.
1.1. Determine the input and output equipment.
1.2. Set the input-to-output routing and priority.
2. Prepare equipment.
2.1. Mount modules. (Refer to p. 88.)
2.2. Check to confirm that the Mode switch is set to the matrix mode. (Refer to p. 25.)
2.3. Connect the power source to the unit using the power cord, then turn on the power switch.
3. Perform equipment settings.
3.1. Select the operation method. (Refer to p. 35.)
3.2. Set the input parameters. (Refer to p. 40.)
3.3. Set the audio output names. (Refer to p. 45.)
3.4. Set the Event. (Normal matrix operation only) (Refer to p. 46.)
3.5. Set the utility function. (Refer to p. 51.)
3.6. Perform preliminary settings for the adjustment function. (Refer to p. 65.)
3.7. Set the key lock function. (Refer to p. 77.)
3.8. Switch off the power. (Refer to p. 28.)
5. Adjust equipment.
5.1. Switch on the power. (Refer to p. 28)
5.2. Make adjustments while monitoring the sound. (Refer to p. 65.)
6. Operate the system.
• Activate set broadcast patterns through remote control. (Refer to p. 114.)
• Perform operation using the front panel keys and knobs. (Refer to p. 28.)
• Make paging calls. (Refer to p. 30.)
11. SYSTEM DESIGN-TO-OPERATION FLOW
4. Install equipment.
4.1. Mount equipment in a rack. (Refer to p. 100.)
4.2. Perform connections. (Refer to p. 91.)
