87
[Delay Time Settings]
Setting Item Setting Range
Delay Time 0 – 682.6 ms, 0.021 ms steps
ON/OFF ON, OFF
Filter Type Setting Item Setting Range
Parametric Equalizer Gain –15 to +15 dB (0 dB
), 0.1 dB steps
(PEQ) Center frequency 20 Hz – 20 kHz (1 kHz
), 1/24 octave steps
Q 0.267 – 69.249 (96 points)
High-pass Filter (HPF) Cutoff frequency 20 Hz – 20 kHz (1 kHz), 1/24 octave steps
Slope
6 dB/oct 12 dB/oct
Q 0.500 – 2.563 (51 points)
Low-pass Filter (LPF) Cutoff frequency 20 Hz – 20 kHz (1 kHz), 1/24 octave steps
Slope
6 dB/oct 12 dB/oct
Q 0.500 – 2.563 (51 points)
High Shelving Filter Gain –15 to +15 dB (0 dB), 0.1 dB steps
Roll-off frequency 6 – 20 kHz, 1/24 octave steps
Low Shelving Filter Gain –15 to +15 dB (0 dB), 0.1 dB step
Roll-off frequency 20 – 500 Hz, 1/24 octave steps
Horn Equalizer (Horn EQ) Gain 0 to +18 dB, 0.5 dB step
Notch Filter Center frequency 20 Hz – 20 kHz (1 kHz), 1/24 octave steps
Q 8.651
, 9.889, 11.538, 13.847, 17.310,
23.081, 34.623, 69.249
All-pass Filter Center frequency 20 Hz – 20 kHz (1 kHz), 1/24 octave steps
Q 0.267 – 69.249 (96 points)
ON/OFF ON, OFF
[Filter Settings]
[Crossover Settings]
Setting Item Setting Range
Cutoff Frequency 20 Hz
–
20 kHz (1 kHz), 1/24 octave steps
Slope Through, 6 dB/oct, 12 dB/oct BS, 12 dB/oct VQ 24 dB/oct VQ
BS: Bessel 12 dB/oct BW, 12 dB/oct LR, 18 dB/oct BS, 18 dB/oct VQ
BW: Butterworth 18 dB/oct BW, 24 dB/oct BS, 24 dB/oct BW,
LR: Likwitz-Riley 24 dB/oct LR
VQ: Variable Q
Q 0.500
–
2.563 0.500
–
2.563
(51 points) (51 points)
Q2 0.500
–
2.563
(51 points)
GAIN
–
15 to +15 dB (0 dB), 0.1 dB steps
Polarity NORMAL, INVERSE
[Bus Assignment and Crosspoint Gain Settings]
Setting Item Setting Range
Input 1
Output 1 – 8: ON, OFF
Microphone Bus: ON, OFF
Input 2 – 12 Same as above
Microphone Bus
Output 1 – 8: ON, OFF
Gain
–∞ to 0 dB
, 1 dB steps
