24.6.5. AN-001T
+24 V DC, –24 V DC, +6 V DC
20 mA (at +24 V DC), 20 mA (at –24 V DC), 60 mA (at +6 V DC)
Sensor input (Ambient noise sensor microphone input): 2 channels,
3 kΩ (when the phantom power is ON)/10 kΩ (when the phantom power is OFF),
electronically-balanced, removable terminal block (3 pins)
–60, –54, –48, –42, –36, –30, –24, –18, –10 dB* (selectable)
+24 V DC
24 bit ∆∑ADC
48 kHz
Sensor input reference level adjustment function
Maximum output signal level control: –15 to 0 dB
Minimum output signal level control: –18 to – 3 dB
Sample time setting: 10 s, 15 s, 20 s, 30 s, 1 min, 2 min, 3 min, 5 min
Gain ratio setting (Ambient noise to Output signal level):
6:3, 5:3, 4:3, 3:3, 3:4, 3:5, 3:6, 6:–3, 5:–3, 4:–3, 3:–3, 3:–4, 3:–5, 3:–6
–10 to +40°C
Panel: Aluminum, hair-line
35 (w) x 78 (h) x 91.5 (d) mm
82 g
Power Source
Current Consumption
Input
Input Sensitivity
Phantom Power
A/D Converter
Sampling Frequency
Ambient Noise Control
Function
Operating Temperature
Finish
Dimensions
Weight
* 0 dB = 1 V
Note: The design and specifications are subject to change without notice for improvement.
• Accessories
Removable terminal plug (3 pins) .................... 2
Machine screw M3 x 8 ..................................... 2
