51
Chapter 6 Configurations
Switch Access Control 6.1
The MultiLoad II contains switches which limit menu and configuration access. These switches limit
users from accessing Program Mode, as well as from changing Weights and Measures controlled
parameters.
In Program Mode, the operator has access to the following:
- The Configuration Menu parameters.
- The Diagnostics Menu and its functions.
- Other administrative procedures, such as clearing high-level alarms.
To access Program Mode, the MultiLoad II/ RCU II terminal operator must:
1. Move the Program Mode switch into the active position.
2. At the idle card-in screen, enter the security code (default security code is 000000) and press
the <Next> key.
External Switch Access Control (MultiLoad II Only)
6.1.1
One access control switch option is a pair of external access control switches. These switches limit
access to Program Mode and changes to Weights and Measures controlled parameters.
EXTERNAL SWITCHES SERVE NO FUNCTION ON THE RCU II SINCE PASSWORD ACCESS ALWAYS
OVERRIDES THE PROGRAM SWITCH SETTING. WEIGHTS AND MEASURES FUNCTIONALITY IS
UNDEFINED FOR THE RCU II.
YOUR LOCAL WEIGHTS AND MEASURES OFFICE MAY NEED TO BE CONTACTED AFTER BREAKING THE
SEAL AND CHANGING PARAMETERS. THIS IS TYPICALLY DONE ONLY DURING METER PROVING OR
TEMPERATURE CALIBRATION.
