8) Press Exit to return to the Configuration Menu.
9) Select and press Enter to return to the Main Menu.
10) If the MultiLoad II/ RCU II has a Program/Weights and Measures switch, return the switch to
Operating Mode.
Verifying Communications between MultiLoad II/ RCU II and I/O Board 6.6
1) Enter program mode by pressing 00000 on the keypad, then press Next key.
2) Select diagnostics from main menu:
MultiLoad II RCU II
3) For MultiLoad II, select FCM COM. For RCU II, select RCU:
MultiLoad II RCU II
4) If screen displays “00-OK” (or “I/O Board Com: OK” for the RCU II), the I/O board is communicating
with the MultiLoad II or RCU II.
5) If the I/O board is not communicating the message “00-ERR” appears (or “I/O Board Com: ERR” for
the RCU II).
D I A G N O S T I C S M E N U
Card Reader
COM Loopback
Serial Ports
Network Test
Keypad
Display
Unicode
RCU
Next Prev Exit Enter
000 FCM COM DIAGNOSTICS
00-Ok
Exit
RCU I/O DIAGNOSTICS
I/O Board Com: Ok F/W Rev: 033
Timeouts: 000000003 Com Lost: 000000001
[1]AC Output 0 - OFF DC Input 4 – OFF
[2]AC Output 1 - OFF DC Input 5 – OFF
[3]AC Output 2 - OFF DC Input 6 – OFF
[4]AC Output 3 - OFF DC Input 7 – OFF
[5]AC Output 8 - OFF DC Input 9 – OFF
[6]DC Output 10 – OFF Counter 4 - 00000
[6]DC Output 11 – OFF Counter 5 - 00000
[6]DC Output 12 – OFF Program Key– OFF
W&M Key – OFF
Battery @ 36C 3.24V
Battery 100%
Exit Clear
D I A G N O S T I C S M E N U
Card Reader Preset
COM Loopback Meters
Serial Ports Components
PTB Serial –Test Additives
Network Test Sampler
Keypad Custom Logic
Display Modbus Device
Unicode Thread Info
FCM Com SD Card
PCM Com
FCM Health
PCM Health
RCU
Bay
Next Prev Exit Enter
