Toptech RCU II DIV2 User Manual

58
To return to the Main Menu, press EXIT. To return to any previous screen, press the EXIT key.
Field Modification and Data Entry
6.4
MultiLoad II/ RCU II will have all fields populated with default values. There are two types of fields,
toggle or data entry. Toggle fields contain a number of choices. Scroll through the choices by pressing
the Enter key. Data entry fields require that a value be entered into the field within a given, applicable
range. In the example below, RCU Address field is highlighted:
Press ENTER to choose the field. A blinking cursor indicates that data can be entered.
Type in the new value (e.g. 123) and press ENTER. The new value displays on the screen.
RCU GENERAL SETUP
RCU Address: 001
Card Reader: DISABLD
Processing Mode : Remote
Swing Arn Secondary: DISABLD
Terminal Name: Toptech Terminal
Security Accounts
Next Prev Exit Enter
RCU GENERAL SETUP
RCU Address: █
Card Reader: DISABLD
Processing Mode: Remote
Swing Arm Secondary: DISABLD
Terminal Name: Toptech Terminal
Security Accounts
Enter Exit
