Toptech RCU II DIV2 User Manual

81
02/08/2011
Released 2 Meter I/O board option (IO_2M rev 1.0).
02/08/2011
Capacitive keypad option released (RCUII_DIVII_SOLID_STATE_KP rev 1.0).
03/08/2011
Changed regulatory agency from CSA to Intertek.
01/17/2012
Replaced relay assemblies on I/O board with discrete triacs (IO_DA rev 1.2, IO_2M
rev 1.1).
06/07/2013
Added 2-wire 485 to COM2, thru hole ethernet socket, pluggable 5V inter-board
header, new DC supply not transformer isolated (AC-INT rev 1.2; DC-INT rev 1.2).
10/01/2014
Improved RTD filtering (IO_DA rev 1.3, IO_2M rev 1.2).
09/24/2015
Released SCS_IO board (rev 1.0).
Manual Revision 9.2
Revision
Date
Description
(RCU)
07/18/2006
Original release; mostly a port of RCU I but with pictures of RCU II
components.
1.0 (ML)
08/03/2007
Release.
1.1 (ML)
02/21/2008
Expanded I/O section to show FCM I and FCM II wiring connections;
described FCM comm. wiring in chapter 4; reorganized serial comm
description by function not port.
1.2
(RCU)
08/21/2008
Added European Declaration of conformity and all international
warnings;
1.2 (ML)
04/18/2008
Formatting change. No content change.

Toptech RCU II DIV2 Specifications

General

Brand	Toptech
Model	RCU II DIV2
Category	Controller
Language	English
