Batteryterminalsormetaltoolscouldshort
againstmetaltractorcomponentscausing
sparks.Sparkscancausethebatterygassesto
explode,resultinginpersonalinjury.
•Whenremovingorinstallingthebattery,do
notallowthebatteryterminalstotouchany
metalpartsofthetractor.
•Donotallowmetaltoolstoshortbetween
thebatteryterminalsandmetalpartsofthe
tractor.
Figure10
1.Negative(-)2.Positive(+)
3.Connecttheblackgroundcable(fromtheengine
base)tothenegative(-)postofthebattery.Secureit
withawrenchandcoattheterminalwithpetroleum
jelly.
Incorrectbatterycableroutingcoulddamage
thetractorandcablescausingsparks.Sparks
cancausethebatterygassestoexplode,
resultinginpersonalinjury.
•Alwaysdisconnectthenegative(black)
batterycablebeforedisconnectingthe
positive(red)cable.
•Alwaysconnectthepositive(red)battery
cablebeforeconnectingthenegative(black)
cable.
4.Installthebatteryclampandwashersandsecure
themwiththewingnuts.
5.Placetheterminalcoveroverthepositive(+)battery
post.
4
InstallingtheCuttingUnits
(ForCuttingUnitModels04610
and04611Only)
Partsneededforthisprocedure:
1
Gaugebar
1
Bolt(#10x5/8inch)
1
Jamnut(#10)
3
Cuttingunit
6Washer
6Ballstud
3
Grassbasket
Procedure
Note:Whensharpening,settingtheheight-of-cut
orperformingothermaintenanceproceduresonthe
cuttingunits,storethecuttingunitreelmotorsinthe
supporttubesonthefrontoftheframetoprevent
damagetothehoses.
1.Removethecuttingunitsfromthecartons.Assemble
andadjustthemaslistedinthecuttingunitOperator’s
Manual.Usethegaugebarfromtheloosepartskit
toadjusttheheightofcut.
2.Mountawasherandballstudtoeachendofthe
frontrolleronthecuttingunits(Figure11).
Figure11
1.Pullframe
3.Ballstud
2.Pullarm
3.Slidethecuttingunitunderthepullframewhile
hookingthelifthookontotheliftarm(Figure12).
