Figure27
BeforeStart(oilcold)
1.Fillercap
5.Solenoidreturnvalveopen
2.Fillerneck6.Floatraisedswitchopen
3.Overowtube
7.Nosound
4.Sightwindow8.Fluidlevel(cold)
Figure28
NormalOperation(oilwarm)
1.Solenoidreturnvalve
closed
3.Warningbuzzer
2.Floatraisedswitchopen
4.Fluidlevel(warm)
Figure29
LeakAlert!
1.Floatdownswitchclosed
Fluidleveldown4to6
ounces(118–177ml)
3.Fluidlevel(warm)
2.Warningbuzzer
CheckingtheSystemOperation
1.WithignitionswitchintheOnposition,movethe
leakdetectorswitchrearwardandhold.Afterthe
one-secondtimedelayelapsesthealarmshould
sound.
2.Releasetheleakdetectorswitch.
CheckingtheLeakDetectorSystem
Operation
1.MovetheignitionswitchtotheOnposition.Do
notstarttheengine.
2.Removethehydraulictankcapandstrainerfrom
theneckofthetank.
3.Insertacleanrodorscrewdriverintothetank
neckandgentlypushdownontheswitchoat
(Figure30).Thealarmshouldsoundafterthe
one-seconddelay.
