Toro 74265TE - Positioning the Flow Baffle

5.Swingtheleverbackovertotightenthebafeandcam
locks(Figure34).
6.Ifthecamlocksdonotlockthebafeintoplaceoritis
tootight,loosentheleverandthenrotatethecamlock.
Note:Adjustthecamlockuntilthedesiredlocking
pressureisachieved.
g027727
Figure34
PositioningtheFlowBafe
Thefollowingguresareonlyrecommendationsforuse.
Adjustmentsvarybygrasstype,moisturecontent,andthe
heightofthegrass.
Note:Iftheenginepowerdrawsdownandthemower
groundspeedisthesame,openupthebafe.
PositionA
Thisisthefullrearposition.Thesuggesteduseforthis
positionisasfollows:
•Short,lightgrassmowingconditions
•Dryconditions
•Smallergrassclippings
•Propelsgrassclippingsfartherawayfromthemower
g005832
Figure35
PositionB
Usethispositionwhenbagging.Alwaysalignitwiththe
bloweropening.
g005833
Figure36
PositionC
Thisisthefullopenposition.Thesuggesteduseforthis
positionisasfollows:
•Tall,densegrassmowingconditions
•Wetconditions
•Lowerstheengine-powerconsumption
•Allowsincreasedgroundspeedinheavyconditions
g005834
Figure37
