Toro 74265TE - Using the Z Stand

g027996
5
1
2
6
g027996
Figure41
1.Full-widthrampinstowed
position
4.Rampisatleast4times
aslongastheheightof
thetrailerortruckbedto
theground
2.Sideviewoffull-width
rampinloadingposition
5.H=heightofthetraileror
truckbedtotheground
3.Notgreaterthan
15degrees
6.Trailer
UsingtheZStand™
TheZStand™raisesthefrontendofthemachinetoallow
youtocleanthemowerandremovetheblades.
WARNING
Themachinecouldfallontosomeoneandcause
seriousinjuryordeath.
•Useextremecautionwhenoperatingthe
machineontheZStand™.
•Useonlyforcleaningthemowerandremoving
theblades.
•DonotkeepthemachineontheZStand™for
extendedperiodsoftime.
•Alwaysturntheengineoff,settheparking
brake,andremovethekeybeforeperforming
anymaintenancetothemower.
DrivingupontotheZStand™
Important:UsetheZStand™onalevelsurface.
1.RaisethemowertotheTRANSPORTposition.
2.Removethebracketpin(Figure42).
g001811
Figure42
1.ZStand™
4.Bracketpin
2.Latch
5.Bottomofslot
3.Bracket
3.Raisethelatch.Swingthestandfootoutfrontand
slidestandtowardmachine,intothebottomofslot
(Figure42andFigure43).
4.LengthentheZStand™byremovingtheclevispin
andhairpincotterfromtheoutertubeandslidingthe
footout.
5.Aligntheholesandinstalltheclevispinandhairpin
cotterpin.
33
