g001812
Figure43
1.ZStand™(Positionedin
slot)
3.Latchrestingonpivottab
2.Crackinsidewalkorturf
6.Setthefootofstandonthegroundandrestthelatch
onthepivottab(Figure43).
7.Starttheengineandputitathalfthrottle.
Note:Forbestresults,placethefootofstandinto
seamsinsidewalksorintotheturf(Figure43).
8.Driveontothestand.Stopwhenthelatchdropsover
thetabintotheLOCKEDposition(Figure43).Once
ontothestand,engagetheparkingbrakeandshutoff
theengine.
9.Chockorblockthedrivewheels.
WARNING
Theparkingbrakemaynotholdthemachine
thatisparkedontheZStand™andcould
causepersonalinjuryorpropertydamage.
DonotparkontheZStand™unlesswheels
arechockedorblocked.
10.Performthemaintenanceonthemachine.
DrivingofftheZStand™
1.Removethechocksorblocks.
2.RaisethelatchtotheUNLOCKEDposition(Figure44).
g001813
Figure44
1.ZStand™
3.LOCKEDposition
2.Latch4.UNLOCKEDposition
3.Starttheengineandplaceitathalfthrottle.Disengage
theparkingbrake.
4.Slowlydrivebackwardoffthestand.
5.ShortentheZStand™byremovingtheclevispinand
hairpincotterpinfromtheoutertubeandslidingthe
footin.
6.Aligntheholesandinstalltheclevispinandhairpin
cotterpin.
7.ReturnthestandtoitsRESTposition(Figure42).
