Toro 74265TE - Replacing the Pump Drive Belt

7.InstallthePTO-drivebeltaroundtheclutchpulleyand
thegearboxpulley(Figure86).
8.Intalltherubberclutchstop.
9.Installthespringtotheidlerarm(Figure86).
g007176
Figure86
1.Gearbox4.Clutch
2.Spring
5.Rubberclutchstop
3.Spring-loadedidlerpulley6.PTO-drivebelt
ReplacingthePumpDriveBelt
ServiceInterval:Every50hours—Checkthepumpdrive
belt.
Note:RemovethePTO-drivebeltrstifthepumpdrive
beltneedstobereplaced.
1.Tilttheseatforwardandremovethefrontenginepanel.
2.RemovethePTO-drivebelt.
3.Removethespringfromtheidlerarm(Figure87).
4.Installthenewbeltaroundtheengineandhydraulic
pumppulley(Figure87).
5.InstallthePTO-drivebelt.
6.Installthespringtotheidlerarm(Figure87).
g007177
Figure87
1.Clutch3.Spring
2.Pumpdrivebelt
4.Spring-loadedidlerpulley
ReplacingandTensioningthe
AlternatorBelt
ReplacingtheAlternatorBelt
ServiceInterval:Every50hours—Checkthealternatorbelt.
Ifthealternatorbeltneedstobereplace,takeyourmachine
toanAuthorizedServiceDealer.
TensioningtheAlternatorBelt
1.Placeahandlebetweenthealternatorandcylinder
block.
2.Adjustthealternatortotheoutsideuntilthereis7to9
mm(1/4to11/32inch)deectioninthebeltbetween
theengineandthealternatorpulleyswith10kgf(22.1
lbofforce)(Figure88).
3.Tightenthealternatorbolts.
4.Checkthedeectioninthebeltagainandadjustthe
beltifneeded.
5.Ifthedeectioniscorrect,tightenthebottomand
upperbolt(Figure88).
58
