6.Torquetheange-headboltsandangelocknuts
to1978to2542N∙cm(175to225in-lb).
7.Tightenthe2angeclampsbyhand(Figure
121).
8.Assemblethequick-connectcouplerofthe
sectionhoseontothequick-connectttingofthe
section-valvemanifoldwiththequick-connect
pin(Figure120).
9.Ifyouloosenedthemountinghardwareoftheleft
orrightsection-valvemanifolds,tightenthenut
andboltto1978to2542N∙cm(175to225in-lb).
InstallingtheAgitation-Manifold
Valve
1.Aligntheangeoftheagitation-valvemanifold
and3gasketswiththeangesofthe
agitation-bypassvalve,pressurelterhead,and
couplingadapter(Figure122andFigure123).
Note:Ifneeded,loosenthemountinghardware
forthepressure-lterheadasneededtoprovide
clearance.
g191302
Figure122
1.Manifold(agitationvalve)4.Flange-headbolt(1/4x
3/4inch)
2.Valvesupport
5.Gasket
3.Flangelocknut(1/4inch)
g191301
Figure123
1.Flange(pressure-lter
head)
4.Quick-connectpin
2.Flange(couplingadapter)5.Quick-connectcoupler
(agitationhose)
3.Flangeclamp
6.Quick-connecttting
(agitationvalvemanifold)
2.Looselysecuretheagitation-valvemanifoldto
theagitation-bypassvalve,pressurelterhead,
andcouplingadapter(Figure123)withthe3
angeclampsthatyouremovedinRemoving
theAgitation-ManifoldValve(page80).
3.Assembletheagitation-valvemanifoldtothe
valvesupportwiththe2ange-headbolts(1/4
x3/4inch)and2angelocknuts(1/4inch)that
youremovedinRemovingtheAgitation-Manifold
Valve(page80).
4.Torquetheange-headboltsandangelocknuts
to1978to2542N∙cm(175to225in-lb).
5.Tightenthe3angeclampsbyhand(Figure
123).
6.Assemblethequick-connectcouplerofthe
agitationhoseontothequick-connecttting
oftheagitation-valvemanifoldwiththe
quick-connectpin(Figure123).
7.Ifyouloosenedthemountinghardwareforthe
pressure-lterhead,tightenthenutandboltto
1978to2542N∙cm(175to225in-lb).
85
