Note:Youmustsitintheoperatorseatbeforeyou
movethemachine;otherwise,themachinewillnot
move.
Note:Theutility-tractionlevercontrolsthespeedof
themachine.Thefartherthatyoumovetheleverfrom
theNeutralposition,thefasterthemachinemoves.
Important:Controlthespeedofthemachine
travelwiththeutility-tractionlever,notthethrottle.
5.Checktheindicatordisplayfrequently.
UsingtheBackllBlade
Important:Operatethecontrolswhilesittinginthe
operatorseat.
Usethebackllbladetoreturnthespoilsintothe
trench.Youcontrolthebackllbladewiththe
backll-blade/vibratory-plowjoystick.Usethejoystick,
trigger,andthumbswitchasshowninFigure48.
Figure48
1.Lowertheblade(joystick)5.Turnthebladeleft
(left-thumbcontrol)
2.Raisetheblade(joystick)
6.Turnthebladeright
(right-thumbcontrol)
3.Tiltthebladeleft(joystick)7.Floattheblade(trigger)
4.Tiltthebladeright
(joystick)
1.Switchthemachinetothebackllbladefunctionby
pressingbutton5onthecommandcenteruntilthe
iconforthebackllbladeappears(Figure49).
Figure49
1.Button5—backllblade/vibratoryplowselection
(backll-bladeiconshown)
2.Tooperatethebackllblade,dothefollowing:
•Tolowerthebackllblade:Movethejoystick
forward(Figure50).
•Toraisethebackllblade:Movethejoystick
rearward(Figure50).
Figure50
1.Lowerthebackllblade2.Raisethebackllblade
•Totiltthebackllbladedownontheleft:Movethe
joystickleft—towardyou(Figure48andFigure51).
•Totiltthebackllbladedownontheright:Move
thejoystickright—awayfromyou(Figure48and
Figure52).
Figure51
1.Down—left
2.Down—right
39
