Battery Service (continued)
4. Charge the battery for 1 hour at 25 to 30 A or 6 hours at 4 to 6 A.
IMPORTANT
Do not overcharge the battery.
g003792
Positive battery post
Negative battery post
Red (+) charger lead
Black (-) charger lead
5. When the battery is fully charged, unplug the charger from the electrical outlet, and
disconnect the charger leads from the battery posts.
6. Install the battery onto the machine and connect the battery cables.
Note: Do not run the machine with the battery disconnected; electrical damage may
occur.
Installing the Battery
g185906
1. Place the battery on the platform and secure it
using the 2 wing nuts
and the securing rod
.
2. Install the positive battery cable
to the
battery.
3. Install the negative battery cable
to the
battery.
3462-915A Page 5–14 Maintenance: Electrical System Maintenance
