Toro Workman UTX - Troubleshooting; Problem Diagnosis and Fault Codes

Troubleshooting
Problem
PossibleCauseCorrectiveAction
1.Yourfootisnotonthebrakepedal.1.Putyourfootonthebrakepedal.
Theenginedoesnotcrankover.
2.Thebatteryisdeadand/orthereisa
badbatteryconnection.
2.Checkthebatteryconnections.Ifthe
batteryisdead,replacethebattery.
1.Thefueltankisempty.1.Fillthefueltank.
2.Thereisdirt,water,orstalefuelinthe
fuelsystem.
2.ContactyourauthorizedT oro
distributor.
3.Theaircleanerisdirtyorplugged.
3.Cleanorreplacetheaircleaner.
Theenginecranks,butdoesnotstart.
4.Thesparkplug(s)arefouledorgapped
improperly.
4.Replacethesparkplug(s).
1.Thereisablownfuseintheelectrical
system.
1.Inspectandreplacethefuse.
2.Thepowersteeringcontrolleris
disconnected.
2.Connectthepowersteeringcontroller.
Thepowersteeringmoveshard.
3.Thepowersteeringmotorand/or
controllerisbad.
3.Replacethepowersteeringmotor
and/orcontroller;contactyour
authorizedTorodistributor.
1.ThetransmissionleverisintheP
(PARK)position,N(NEUTRAL)position,
orbetweengears.
1.Shiftthetransmissionleverintoadrive
position.
2.The“noseatbelt”featureissetto0
km/hormph.
2.Secureyourseatbelt.
Thethrottleisnotresponding.
3.Thegearpositionsensoris
non-functionalordamaged.
3.ContactyourauthorizedT oro
distributor.
1.Thereisablownfuseintheelectrical
system.
1.Inspectandreplacethefuse.
2.Thefeaturewasdisabledduring
softwaresetup.
2.ContactyourauthorizedT oro
distributor.
3.Theswitchesand/ordifferential(s)are
unplugged.
3.Inspectandreconnecttheharness.
The4-wheeldrive/differentiallocksarenot
working.
4.Theactuator/solenoidisbad.
4.ContactyourauthorizedT oro
distributor.
1.Yourseatbeltisnotsecured.
1.Secureyourseatbelt.
Thecruisecontrolfeaturedoesnot
engage.
2.Youarenottravelingattheminimum
machinespeed.
2.Increasethemachinespeedtosetthe
cruisecontrol.
1.Thebeltisnew.
1.Allow10hoursofnormaloperationfor
thebeltbreak-inperiod.
Theclutchengagementisabrupt.
2.Theclutchesaredirty.
2.Cleantheclutches.
1.Thebeltisslippingand/ordamaged.1.Checkthebelt;replace,ifneeded.
Theaccelerationseemstooslowwhen
theengineisatmaximumspeed(rpm).
2.Theclutchesaredirty.
2.Cleantheclutches.
1.Theenginebeltislooseand/or
damaged.
1.Checkthebelt;replace,ifneeded.
2.Thereisabadelectricalconnectionto
thealternator.
2.Checktheharnessconnection.
3.
Thealternatorisbad.
3.ContactyourauthorizedT oro
distributor.
Thebatteryisnotcharging.
4.Thebatteryisdeadand/orthereisa
badbatteryconnection.
4.Checkthebatteryconnections.Ifthe
batteryisdead,replacethebattery.
