Lubrication

GreasingtheMachine

ServiceInterval:Every250hours—Greasethe

machine(lubricatemorefrequently

inheavy-dutyapplications).

GreaseType:No.2lithiumgrease

1.Usearagtowipethegreasettingcleansothat

foreignmattercannotbeforcedintothebearing

orbushing.

2.Withagreasegun,applygreaseintothegrease

ttingsonthemachine.

3.Wipeanyexcessgreaseoffthemachine.

Thegreasettinglocationsandquantitiesareas

follows:

•Frontcontrolarmpivots(2);refertoFigure79

g390951

Figure79

Rightsideshown

1.Frontcontrolarmpivotgreasetting

•Rearcontrolarmpivots(4);refertoFigure80

g390953

Figure80

Rightsideshown

1.Rearcontrolarmpivotsgreasettings

•Balljoints(2);refertoFigure81

g390950

Figure81

Rightsideshown

1.Balljointgreasetting
