Toro Workman UTX User Manual

Setup
Note:Determinetheleftandrightsideofthemachinefromthenormaloperatingposition.
1
InstallingtheSteering
Wheel
TCModelsOnly
Partsneededforthisprocedure:
1
Steeringwheel
1
Cover
Procedure
1.Ifthecoverisinstalled,removeitfromthehub
ofthesteeringwheel.
2.Removethelocknut(1/2inch)fromthesteering
shaft.
3.Ensurethatthefrontwheelsarecentered.
4.Slidethesteeringwheelontothesteeringshaft.
5.Securethesteeringwheeltotheshaftusing
thepreviouslyremovedlocknut(1/2inch)and
tightenitto24to30N∙m(18to22ft-lb).
6.Installthecoverontothesteeringwheel.
g357124
Figure3
1.Cover3.Steeringwheel
2.Locknut(1/2inch)4.Steeringshaft
9
