7 TROUBLESHOOTING

212 Replacing Toner Cartridge

Shake the new toner cartridge strongly with the label surface down to loosen the toner

inside.

Pull out the seal in the direction of the arrow.

Insert the toner cartridge along the rail.

Insert the toner cartridge until you hear a click sound.
