7.TROUBLESHOOTING

Replacing Toner Cartridge 213

7 TROUBLESHOOTING

Clean the charger.

Hold the cleaning knob of the charger and pull it out toward you carefully until it stops. Then reinsert it in

its original position carefully. Repeat this procedure two to three times.

Check if the cleaning knob is fully inserted after cleaning.

Close the front cover.
