e-STUDIO5506AC/6506AC/7506AC (Ver01) © 2016, 2017 TOSHIBA TEC CORPORATION All rights reserved
3-14
3. Printer-specific Adjustments
* “Halftone” refers to how halftones are printed. Two options are available: “Smooth” which is intended to
improve the reproducibility of gradation and “Detail” which is intended to print halftones in details (with
the high frequency).
The halftone option to be applied in printing can be selected from among the “Halftone” options on the
printer driver (Windows) or in the print dialog box (Macintosh).
“Auto” is selected from among the “Apply to” options by default. It is intended to automatically select
“Smooth” or “Detail” in accordance with “Apply to” of the halftone option, the selected “Color” and
“Image Quality Type” options, as described in the table below.
Apply to
“Color” and “Image Quality Type” options
Text Detail Detail Detail Detail Detail Detail
Graphic
(Illustration, line, etc.)
Smooth Smooth Smooth Detail Smooth Smooth
(Photograph, etc.)
Smooth Smooth Smooth Detail Smooth Smooth
* The subcode varies according to the area where the density is adjusted. Refer to the table below and set the
subcode for the area to be adjusted.
Area where the density is adjusted
<Note> • This adjustment changes the values set in the MFP. Therefore, it will affect every user who
uses the printer by connecting it to the MFP. After the adjustment, the values changed will be
applied to all printouts for the “Image Quality Type” and “Halftone” options. (For instance, if
the value for [05] code for PCL6 and Smooth is changed, it will be applied to printing
performed with PCL6 and Halftone = “Smooth” (or “Auto”) selected.) Carefully perform the
adjustment, being aware that the image quality of all future printouts will be changed, when
printing out originals other than the one that is used for the adjustment.
Precautions after the completion of the adjustment
Nothing in particular.
