Appendix B Board Layout Appendices
PORTÉGÉ Z930/Satellite Z930 Series Maintenance Manual (960-887) [CONFIDENTIAL] B-9
B.5 Finger sensor board (FULFS*) View
(front)
(back)
Figure B-5 Finger sensor board (FULFS*) layout (front/back)
Table B-5 Finger sensor board (FULFS*) connector (front/back)
Number Name
CN3650 FAU2TP* board interface connector
