Toshiba PORTEGE Z930 User Manual

Appendices Appendix C Pin Assignments
C-14 [CONFIDENTIAL] PORTÉGÉ Z930/Satellite Z930Series Maintenance Manual (960-887)
75
GND
76
GND
1T
GND
2T
GND
C.19 CN9540 WebCam interface connector (6-pin)
Table C- 19 WebCam interface connector (6-pin)
Pin No. Signal Name Pin No. Signal Name
1
P3V
2
ZUSBWC-E3N
3
ZUSBWC-E3P
4
GND
5
GND
6
CAMDET-P3N
1T
GND
2T
GND
C.20 CN9550 FAU2TP* board interface connector (22-pin)
Table C- 20 FAU2TP* board interface connector (22-pin)
Pin No. Signal Name Pin No. Signal Name
1 IPDCLK-P5P 2 GND
3 IPDDAT-P5P 4 P5V
5 DCINOR-S5N
6
M5V
7 DCINGR-S5N
8
PWLEOR-S3P
9 PWLEGR-S3P 10 BAT10R-S5N
11 BAT1GR-S5N 12 GND
13 SATLED-P3N 14 P3V
15 ECOLED-S3P 16 RFLED-S3P
17
WANLED-E3P 18 FGSPON-S3N
19
GND
20
ZUSBFS-E3P
21
ZUSBFS-E3N
22
GND
1T
GND
2T
GND
C.21 CN3241 Keyboard Back Light interface connector (4-pin)
Table C- 21 Keyboard Back Light interface connector (4-pin)
Pin No. Signal Name Pin No. Signal Name
1
IC3240-4
2
P5V
3
KBBLDT-P3P
4
GND
1T
GND
2T
GND

Toshiba PORTEGE Z930 Specifications

General

Graphics	Intel HD Graphics 4000
Battery Life	Up to 8 hours
Wireless	Wi-Fi 802.11a/b/g/n, Bluetooth 4.0
Storage	128GB SSD
Display	13.3-inch (1366x768) LED-backlit
Operating System	Windows 7 Professional
Weight	1.12 kg
Ports	HDMI, VGA, Ethernet, SD card slot
Processor	Intel Core i5 or i7
