Toshiba PORTEGE Z930 User Manual

Troubleshooting Procedures
PORTÉGÉ Z930/Satellite Z930 Series Maintenance Manual (960-887) [CONFIDENTIAL] 2-15
2.3.2 Procedure 2 Error Code Check
If the power supply microprocessor detects a malfunction, the DC IN icon blinks orange. The
blink pattern indicates an error as shown below.
 Start Off for 2 seconds
 Error code (8 bit)
“1” On for one second
“0” On for half second
Interval between data bits Off for half second
The error code begins with the least significant digit.
Example: Error code 11h (Error codes are given in hexadecimal format.)
Start

Toshiba PORTEGE Z930 Specifications

General

Graphics	Intel HD Graphics 4000
Battery Life	Up to 8 hours
Wireless	Wi-Fi 802.11a/b/g/n, Bluetooth 4.0
Storage	128GB SSD
Display	13.3-inch (1366x768) LED-backlit
Operating System	Windows 7 Professional
Weight	1.12 kg
Ports	HDMI, VGA, Ethernet, SD card slot
Processor	Intel Core i5 or i7
