Page #185 background image
4.12 VGA Cooling Module and VGA Board 4 Replacement Procedures
Installing the VGA Board
Install the VGA board according to the following procedures and Figure 4-24.
1. Seat the VGA board.
2. Secure the VGA board with two M2x4 black flat head screws.
3. Secure the VGA board thermal module and VGA board bracket with one M2x4 black
flat head screws.
Qosmio F40/F45 Maintenance Manual 4-47
