SAO02 module external wiring
 When mounted on UTBA2
SAO02 module front panel
RUN indicator:
Lights up during normal operation.
Alarm indicator:
Blinks in an abnormal operation.
Module address setting switch:
Sets address numbers 1 to E
(decimal 1 to 14).
AO02
4-20 mAdc
TOSHIBA
RUN
ALM
ADDR
4
C
3
B
2
A
1
9
0
8
F
7
E
6
D
5
GND
(External load)
(TB1/TB2)
FG
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
SAO02
FG
A
O1(+)
A
O1( - )
A
O2(+)
A
O2( - )
A
O3(+)
A
O3( - )
A
O4(+)
A
O4( - )
