3. System Configuration Unit and Module
47
Terminal Block Unit UTBA6
UTBA6 unit specifications
Item Specification
Model name UTBA6
Form of mounting Exclusively for perpendicular mounting on the DIN rail (fixed in
place with M4 screw)
Number of modules that can be
mounted
Up to 2 PI/O modules
Compatible modules SAI06, SAO06
Module dualization Possible (two same modules are mounted)
Compatible option boards FIVC21, FIVC22, FDA01 (Only SAI06 module is usable.)
Compatible short bar Not required
External wire terminal blocks 2 removable type terminal blocks (M3.5 screws, 21 terminals)
Matching external wire size 1.25 mm
2
or less
External power supply
24 Vdc

10%, ripple 5% or less
Maximum current in I/O bus 24 Vdc-2.2 A (total PI/O modules current consumption)
If the power supply capacity exceeds the specification, connect a
power supply relay cable between the terminal blocks.
Accessories 1 I/O bus cable ZCS005A0701
1 blank cover FSCV1
Ability of insulation to withstand
voltage
500 Vac for 1 minute (between external and internal signals)
External dimensions
80 W

240 H

77 D mm (unit by itself, excluding protrusions)
80 W

240 H

120 D mm (with PI/O module mounted, excluding
protrusions)
Weight 750 g or less (this unit by itself)
