3.
System Configuration Unit and Module
56
Relay Connection Unit UTRC1
UTRC1 specifications
Item Specification
Model name UTRC1
Form of mounting Exclusively for perpendicular mounting on DIN rail (fixed in place
with M4 screws)
Number of modules that can
be mounted
Up to 2 PI/O modules
Compatible modules SDI01, SDO01
Compatible short bar Unnecessary
External line connector 4 24-pin connectors exclusively for relay connection use
Compatible external line cable Omron G79-***C cable with connector (1:1)
Compatible relay unit When SDI01 is used: Omron G70A-ZIM16-5 (Note
1)/G7TC-IA16-5/G7TC-ID16-5 (for input use)
When SDO01 is used: Omron G70A-ZOC16-3 (Note
1)/G7TC-OC16/ G7VC-O*16 (for output use)
(Input and output can be intermingled in 32-point units.)
Relay power supply
24V
10% (supply to relay unit side)
Maximum current in I/O bus 24 Vdc-2.2A (total PI/O modules current consumption)
Accessories 1 I/O bus cable ZCS005A0701
1 blank cover FSCV1
Ability of insulation to
withstand voltage
500 Vac for 1 minute (between modules, between external and
internal signal lines)
External dimensions
80 W
240 H
35 D mm (unit alone, excluding protrusions)
80 W
240 H
120 D mm (with PI/O module mounted, excluding
protrusions)
Weight 800 g or less (unit alone)
(Note 1) For connection to G70A relay unit, the round-shaped crimped terminal cannot be used. Please
use the point-opened crimped terminal instead.
