3.
System Configuration Unit and Module
44
Terminal Block Unit UTBA3
UTBA3 specifications
Item Specification
Model name UTBA3
Form of mounting Exclusively for perpendicular mounting on DIN rail
(fixed in place with M4 screws)
Number of modules that can be mounted Up to 2 PI/O modules
Compatible modules Exclusively for use with SAI01 (upper level) and SDA01
( lower level)
Compatible option boards FIVC11, FIVC12
Compatible short bar Unnecessary
External line terminal block 2 removable type terminal blocks (M3.5 screws 21
terminals relation between screws and terminals
unclear)
Matching external line size 1.25 mm
2
or less
External power supply
24 Vdc
10% (21.6 to 26.4 V), ripple 5% or less (for
sensor use)
Maximum current in I/O bus 24 Vdc-2.2 A (total PI/O modules power consumption)
Accessory 1 I/O bus cable ZCS005A0701
Ability of insulation to withstand voltage 500 Vac for 1 minute (between external and internal
signal lines)
External dimensions
80 W
240 H
77 D mm (the unit alone, excluding
protrusions)
80 W
240 H
120 D mm (with PI/O module mounted,
excluding protrusions)
Weight 750 g or less (this unit by itself)
