Terminal Block Unit UTBD1
UTBD1 specifications
Item Specification
Model name UTBD1
Form of mounting Exclusively for perpendicular mounting on DIN rail (fixed in place
with M4 screws)
Number of modules that can be
mounted
1 (mounted on upper side)
Compatible modules SDI01, SDO01
Compatible option board Unnecessary
Compatible short bar FSBR2 (for common wire connection)
External line terminal block 2 removable type terminal blocks (M3.5 screws 21 terminals)
Matching external line size 1.25 mm
2
or less
External power supply
24 Vdc
10%, ripple 5% or less (external load, for contact use)
Maximum current in I/O bus 24 Vdc-2.2 A (total PI/O modules current consumption)
Accessories 1 I/O bus cable ZCS005A0701
1 blank cover FSVC1
1 short bar FSBR2
Ability of insulation to withstand
voltage
500 Vac for 1 minute (between external and internal signal lines)
External dimensions
80 W
240 H
77 D mm (the unit alone, excluding protrusions)
80 W
240 H
120 D mm (with PI/O module mounted, excluding
protrusions)
Weight 900 g or less (unit with short bar attached)
