Apendix 2 External Dimentions
138
Relay Connection Unit
Appended Figure 2.3 Relay connection unit
Module
Appended Figure 2.4 Module
40 95 9
90
A
pplicable module
model name
SBIF1
SAI01
SAI02
SAI03
STC01
SRT01
SAO01
SAO02
SDI01
SDO01
SDA01
SPI01
SPI012
[mm]
SPO01
SBIF2
SAI06
SAO06
