3.
System Configuration Unit and Module
41
Terminal Block Unit UTBA2
UTBA2 specifications
Item Specification
Model name UTBA2
Form of mounting Exclusively for perpendicular mounting on DIN rail
(fixed in place by M4 screws)
Number of modules that can be mounted Up to 2 PI/O modules
Compatible modules SAI02, SAI03, SRT01, SAO02
Compatible option boards FIVC21, FIVC22 (only SAI02 and SAI03 modules can
be used)
Compatible short bar Unnecessary
External line terminal block 2 removable type terminal blocks (M3.5 screws 21
terminals relation between screws and terminals
unclear)
Matching external line size 1.25 mm
2
or less
Maximum current in I/O bus 24 Vdc-2.2 A (total PI/O modules current
consumption)
Accessories 1 I/O bus cable ZCS005A0701
1 blank cover FSCV1
Ability of insulation to withstand voltage 500 Vac for 1 minute (between external signal lines,
between external and internal signal lines)
External dimensions
80 W
240 H
77 D mm (this unit alone, excluding
protrusions)
80 W
240 H
120 D mm (with PI/O module
mounted, excluding protrusions)
Weight 750 g or less (this unit by itself)
